| Business Type | Manufacturer, Exporter, Supplier, Retailer, Trader |
| Number Of Flower | Insulating Castables |
| Material | Cement-based Compound |
| Feature | High Quality, Reliable |
| Click to view more | |
Product Details
Storage Type
Dry Area Recommended
Texture
Powdery With Some Larger Aggregates
Our company has managed to carve a niche in the market for the supply of a wide range of products such as the Insulating Castables which have been bought from reliable vendors in the market and they are tested ensure that they fulfil all the quality parameters set by more
Specification
| Product | General Properties | Chemical Properties | Physical Properties | Thermal Properties | |||||
| Service Temper ature | Grain Size | Water Required for Casting | Al2O3 | Fe2O3 | Bulk Density | Cold Crushing Strength | Refractorin ess Under Load | Permanent Linear Change | |
| UOM | °C (Max) | mm (Max) | mm (Max) | % (Min) | % (Max) | gm/cc | kg/cm2 | °C (Min) | % (at 1500 °C Max) |
| JMD - LC 45 | 1500 | 6.0 | 4.8-5.5 | 45 | 1.0 | 2.30 | 1000 | 1714 | ±1.00 |
| JMD - LC 60 | 1600 | 6.0 | 4.7-5.4 | 60 | 1.5 | 2.60 | 1000 | 1804 | ±1.00 |
| JMD - LC 70 | 1600 | 6.0 | 4.7-5.4 | 70 | 1.5 | 2.70 | 1200 | 1804 | ±1.00 |
| JMD - LC 80 | 1700 | 6.0 | 4.5-6.2 | 80 | 1.8 | 2.90 | 1200 | 1820 | ±0.80 |
| JMD - LC 90 | 1700 | 6.0 | 4.0-4.8 | 90 | 1.0 | 3.10 | 1250 | 1820 | ±0.80 |
